LEGO Train Track Setup #05 | 400m Tracks, Big Bridges, Train Elevator & Automated Switches
LEGO train track setup with 400m tracks, big bridges including a suspension bridge, as well as an automated train elevator and automated switches.
More videos of this setup:
- https://www.youtube.com/playlist?list=PLG1_YWsshyRSg4iVEKI7lgUOeRArV-wke
Installed rails:
450 straight rails (32 studs)
750 straight rails (16 studs)
250 curves R40 (circle=16)
190 curves R56 (circle=16)
200 curves R72 (circle=32)
80 curves R88 (circle=32)
50 curves R104 (circle=32)
50 curves R120 (circle=64)
32 curves R136 (circle=64)
56 switches
38 x-train crossings (2 inputs + 2 outputs)
1 6-way crossings (3 inputs + 3 outputs)
1 20-way crossing (10 inputs + 10 outputs, self 3d printed, see https://youtu.be/ipERA712vko)
200 flexible rails
In total, about 400 meters of rails were used for up to 15 trains.
Additionally, about 28k LEGO pieces have been used for building the bridges, including
- 8k 2x4 bricks
- 6k 2x2 bricks
- 3.5k 2x2 round bricks
- 4k plates (2x4, 2x6, 2x8, 2x14, 2x16, 6x16, 8x16)
The train elevator fits trains up to 2 meters length and covers three layers. Incoming trains are detected and the elevator gets called. Trains on the elevator may choose the destination by color coding, or a random Destination is chosen. More Information can be found here https://youtu.be/whg_i5e356Q
The suspension bridge has a total length of more than 4m, with a span of 2m between the two support pillars. The train roadway is 33 bricks above the ground.
23 of the switches are controlled automatically by LEGO Mindstorms (2x51515) or Powered Up hubs (8xTechnic Hub, 3xCity Hub), i. e. trains are detected by infrared/ distance sensors, which causes the switch to change direction randomly. The powered up hubs are programmed using Pybricks (https://pybricks.com). See https://github.com/Tegowalik/LEGO-Switch-Controller for more information.
Multiple trains are using 2 Powered Up motors (see https://youtu.be/_scBJQutKik and https://github.com/Tegowalik/Pybricks-Train-Controller for more information).
Most of the non LEGO wagons and rails can be bought here: https://www.bluebrixx.com
Most of the non LEGO rails can be bought here:
https://trixbrix.eu/
