The WRONG WAY to Install A Bathroom Sink P Trap Drain With Zero Clearance Below The Wall Drain Pipe

NOTE: It's been brought to my attention that the solution presented in the video is actually an S trap that could potentially allow the water in the trap to be sucked out and sewer gas to pass through. The issue has since been fixed by using an Air Admittance Valve (AAV).

DISCLAIMER: This video is not plumbing advice and was created for entertainment purposes only. The installation shown in the video may not meet your local code or any plumbing code. Do not use this video as a guide to attempt to repair or install plumbing on your own. Please consult a certified plumber for your plumbing repairs.

There's only one solution to modify the S trap shown into a P trap.
Use an Air Admittance Valve at the top horizontal section (between the P trap and the vertical PVC where the water descends). The Air Admittance Valve (AAV) must have a 4 in extension above the pipe. This valve will admit air into the pipe to prevent the negative pressure of water descending the vertical section sucking the water out of the trap.

- Air Admittance Valve AAV - https://amzn.to/3a6wCUg

INCORRECT INFO ONLINE: You may find info online that suggests that you can convert an S trap into a P trap by extending the top horizontal section to at least 2X the P trap diameter (P trap diameter is 1.25in so a 2.5+in horizontal length would work). This used to be permitted in older code but is no longer allowed by code. It is still considered to be an S trap. If the top of the P trap doesn't see the vent in the horizontal direction, it is not right, and still, an S trap which can have its trap water sucked out.

The new bathroom vanity we installed has a fixed shelf that is directly below the drainpipe in the wall. Therefore the P trap can not be installed in its regular location (such that it hangs below the wall drain).

Parts used for the connection:
- P Trap Kit, includes the marvel to PVC adapter - https://amzn.to/2KvPLV8
- 90 Degree 1-1/2in PVC Connector - https://amzn.to/3h1zCmr - Buy 1 of these if you have copper drain pipe at the wall. Buy 2 of these if you have PVC drain pipe at the wall.
- 90 Degree 1-1/2in PVC Connector Spigot x Socket- https://amzn.to/37rjZBy - This is for the lower connection to the wall drain if you have copper drain pipe. You do not need this if you have a PVC wall drain pipe.
- Short Length of 1 1/2in PVC Pipe - https://amzn.to/2WtjyjO
- PVC Cement Glue - https://amzn.to/3h1yPBZ
- Hacksaw to cut the p trap kit and PVC pipes to length - https://amzn.to/3nyrL2f

I tried an off the shelf solution, Snappy Trap, which has a flexible tube after the P trap. Although the Snappytrap bridged the connection between the sink drain and wall drain, it applied so much force that it created stress in the sink drain that could cause leaks in the future. In general, it's not a good idea to apply continuous bending stress to plastics.

Here's a link to the SnappyTrap. It may be useful for other situations. https://amzn.to/2KBl4h8

0:00 Video Timeline
0:03 The Plumbing Problem
0:50 Snappy Trap Fail
2:03 Solution That Works Using Rigid PVC
7:00 Final Install

Installing A Bathroom Sink P Trap Drain With Zero Clearance Below The Wall Drain Pipe Connection PVC
